KYT-7200 |
Manual Insert Type Card Reader(Slim Bezel)
Manual Insert Type Card Reader(Slim Bezel)
KYT-7200
Features
- Compact size & light weight
- Auto lock & auto ejection(Solenoid unlock)
- ISO 7811 MS card full track read
- ISO 7816 Contact IC card read/write (Landing IC contact)
- ISO 14443 Contactless RF card read/write
- Downloadable firmware upgrade and new smart cards support without exchanging H/W
- EMV level 1 Ver4.3c certified
- Green LED indicating operation status
- RS-232C/TTL/USB
Application
- POS terminals
- Kiosk
- Prepaid card terminals
- Access control system
- Vending machines
Specification
| Interface | RS232/USB(Virtual COM)/TTL | Supply Voltage &Current Consumption | Without Load : DC 5V – 100mA With Load : DC5V – 1.5A |
|---|---|---|---|
| Mag. Card type | ISO/IEC 7810 ID-1, ISO/IEC 7811-1,-2,-6 | Total Weight (Kg) | 169g |
| IC Card type | ISO/IEC 7816-1,-2,-3(T=0,T=1) EMV Ver4.3c | Allowance of card thickness | 0.76 (±)0.08mm |
| RF Card Type | ISO-14443A(Mifare, Ultra light) | Interface connector | RS232 : 7IPN, USB: mini B type |
| Magnetic Head life | 500,000 passes | Locus | In the Cabinet |
| IC contact life | 1,000,000 time |
| Interface | RS232/USB(Virtual COM)/TTL |
|---|---|
| Mag. Card type | ISO/IEC 7810 ID-1, ISO/IEC 7811-1,-2,-6 |
| IC Card type | ISO/IEC 7816-1,-2,-3(T=0,T=1) EMV Ver4.3c |
| RF Card Type | ISO-14443A(Mifare, Ultra light) |
| Magnetic Head life | 500,000 passes |
| IC contact life | 1,000,000 time |
| Supply Voltage &Current Consumption | Without Load : DC 5V – 100mA With Load : DC5V – 1.5A |
| Total Weight (Kg) | 169g |
| Allowance of card thickness | 0.76 (±)0.08mm |
| Interface connector | RS232 : 7IPN, USB: mini B type |
| Locus | In the Cabinet |
Model Numbering Table
| Interface | Function | Bezel | Track | Option I | Option II | Option III |
| T : RS-232C L : TTL U : USB |
7 : Manual Insertion MS/IC/RF Card Reader | 0:- 2: Slim Bezel |
0 : Without Magnetic 1 : ISO 1 Track 2 : ISO 2 Track 3 : ISO 3 Track 4 : ISO 1,2 Tracks 5 : ISO 1,3 Tracks 6 : ISO 2,3 Tracks 7 : ISO 1,2,3 Tracks |
0 : Without IC 1 : With IC 4 : IC + SAM 6 : With SAM |
0 : Without RTS & CTS 1 : With RTS & CTS R : Without RS-232C |
0 : – P : RF Card |
| X01 : Without Lock | ||||||
