KHT-2100 |
Metalic Finger Type Card Dispenser (Single Stacker Type)
Metalic Finger Type Card Dispenser (Single Stacker Type)
KHT-2100
Features
- Easy card loading and maintenance
- High reliability with metalic finger type mechanism
- Fundamentally prevent 2 card dispensing with unique clutch system
- Easy adjusting of card thickness between 0.76mm and 1.0mm
- RS-232C or TTL interface
Specification
| Interface | RS232 | Interface Connector | RS232 : 3PIN |
|---|---|---|---|
| Card Loading Capacity | 100/200/300/500 (In Case of 0.76mm Card) | Supply Voltage & Current Consumption |
Without Load : DC 24V – 50mA With Load : DC24 – 2500mA |
| Card Feeding Speed | MAX 1.0(Sec) | Total Weight (Kg) | 2.4Kg ~ 2.8Kg |
| Card Type | ISO standard cards(Non-Embossed) | Applicable Cards | Phone Card, Credit, Debit, Pre-paid, I.C, R/F, Parking Card, etc. |
| Card Material | P.V.C, A.B.S, P.E.T, etc. | Locus | In the Cabinet |
| Max. Card Thickness | 0.76 ~ 1.0 mm |
| Interface | RS232 |
|---|---|
| Card Loading Capacity | 100/200/300/500 (In Case of 0.76mm Card) |
| Card Feeding Speed | MAX 1.0(Sec) |
| Card Type | ISO standard cards(Non-Embossed) |
| Card Material | P.V.C, A.B.S, P.E.T, etc. |
| Max. Card Thickness | 0.76 ~ 1.0 mm |
| Interface Connector | RS232 : 3PIN |
| Supply Voltage & Current Consumption | Without Load : DC 24V – 50mA With Load : DC24 – 2500mA |
| Total Weight (Kg) | 2.4Kg ~ 2.8Kg |
| Applicable Cards | Phone Card, Credit, Debit, Pre-paid, I.C, R/F, Parking Card, etc. |
| Locus | In the Cabinet |
Model Numbering Table
| Interface | Function | Type | Capacity | Thickness | Option |
| T : RS-232C L : TTL |
2 : Dispenser | 1 : Single Stacker | 1 : 100 PCS 2 : 200 PCS 3 : 300 PCS 4 : 500 PCS |
4 : 0.76T 5 : 0.84T 6 : 1.0T |
A : With Bezel B : Without Bezel C : With Bezel & DC Power Jack type D : Without Bezel & DC Power Jack type E : With Shutter F : With Shutter & DC Power Jack type |
